No-Stop Anchor Chain

The studless anchor chain is a high-strength and reliable marine mooring chain, which is widely used in ship anchoring and marine engineering. It is divided into three levels: Class 1 (AM1/U1), Class 2 (AM2/U2), and Class 3 (AM3/U3). It has high strength and is suitable for high-demand scenarios; Class 3 (AM3/U3) studless anchor chain provides the strength and can meet the needs under certain conditions.

Inquiry

No-Stop Anchor Chain
No-Stop Anchor Chain

Product Description

 STUD LINK ANCHOR CHAIN, LINK SIZE(6*3.6D), TEST LOAD AND WEIGHT
 D(φ)
DIAMETER  		 CHAIN LINK
SIZE  		 AM1
U1 STUD LINK CHAIN		 AM2
U2 STUD LINK CHAIN		 AM3
U3 STUD LINK CHAIN		 APPROX. WEIGHT
OUTSIDE
LENGTH 		 OUTSIDE  WIDTH      PROOF LOAD BREAKING      LOAD PROOF LOAD BREAKING
LOAD		 PROOF    LOAD  BREAKING      LOAD 27.5M
INCH MM MM MM KN KN KN KN KN KN KG
1/2 12.5 75 45 28.75 57.81 41.20 82.60 56.40 112.80 85.41
9/16 14 84 50.4 34.78 69.93 51.00 101.90 70.76 141.50 106.55
5/8 16 96 57.6 47.10 94.72 66.20 132.30 92.42 184.83 139.43
11/16 17.5 105 63 56.35 113.31 78.89 157.78 110.55 221.10 178.35
3/4 19 114 68.4 66.42 133.57 93.60 187.20 130.32 260.64 217.68
13/16 20.5 123 73.8 77.33 155.49 108.64 217.27 151.70 303.42 229.14
7/8 22 132 79.2 89.06 179.08 125.40 250.90 174.40 349.40 264.49
15/16 24 144 86.4 105.98 213.25 149.90 298.90 207.90 415.80 341.82
1-1/16 26 156 93.6 124.38 250.12 175.40 350.80 244.00 488.00 369.94
1-1/8 28 168 100.8 144.26 290.08 203.80 406.70 283.00 566.00 427.04
1-3/16 30 180 108 165.60 333.00 234.20 467.50 324.90 649.80 490.98
1-1/4 32 192 115.2 188.42 378.88 265.60 531.20 369.60 739.30 559.65
1-5/16 34 204 122.4 212.70 427.72 299.90 599.80 417.30 834.60 671.52
1-7/16 36 216 129.6 238.46 479.52 336.10 672.30 467.80 935.70 707.85
1-1/2 38 228 136.8 265.70 534.28 374.40 748.70 521.30 1042.50 788.98
1-9/16 40 240 144 294.4 592.00 414.50 829.10 577.60 1155.20 869.36
1-5/8 42 252 151.2 324.58 652.68 457.70 915.30 636.80 1273.60 959.30
1-3/4 44 264 158.4 356.22 716.32 502.70 999.60 698.90 1398.00 1111.25
1-13/16 46 276 165.6 389.34 782.92 548.80 1097.60 763.90 1527.80 1152.07
1-7/8 48 288 172.8 423.94 852.48 597.80 1195.60 831.70 1663.50 1256.26
2 50 300 180 460.00 926.09 648.80 1239.60 902.50 1805.00 1360.41
2-1/16 52 312 187.2 497.54 1000.48 697.63 1395.26 976.14 1952.28 1485.61
2-1/8 54 324 194.4 536.54 1078.92 752.33 1504.66 1052.68 2105.36 1648.08
2-3/16 56 336 201.6 577.02 1160.32 809.09 1618.18 1132.10 2264.20 1715.97
2-5/16 58 348 208.8 618.98 1244.68 867.91 1735.82 1214.40 2428.80 1844.50
2-3/8 60 360 216 662.40 1332.00 928.80 1857.60 1299.60 2599.20 1973.29
2-7/16 62 372 223.2 707.30 1422.28 991.75 1983.50 1387.68 2775.36 2101.56
2-1/2 64 384 230.4 753.66 1515.52 1056.77 2113.54 1478.66 2957.32 2298.47
2-9/16 66 396 237.6 801.50 1611.72 1123.85 2247.70 1572.52 3145.04 2398.10
2-11/16 68 408 244.8 850.82 1710.88 1192.99 2385.98 1669.26 3338.52 2522.88
2-3/4 70 420 252 901.60 1813.00 1264.20 2528.40 1768.90 3537.80 2697.65
